ProFive is the ultimate auto-belay system.
It’s a lead-style auto-belay, anchored at the base of the wall, that
uses a combination of mechanical and electronic systems to let
climbers enjoy lead climbing — even on overhangs — offering a
smooth, unique and engaging experience.
At the end of each session, climbing data will be automatically avai-
lable on ProGrade App to let the climbers analyze their performance
in terms of speed, fluidity, errors, and much more.
Through the Prograde app, gyms can monitor ProFive’s status,
examine the system’s performance, check maintenance schedules,
and access additional insights and statistics.
The data will give your gym deeper insights into climbers’ habits and
skills, helping your gym deliver a more personalized and effective
experience
Product specifics
|
MODEL ProFIVE |
|
|
INSTALLATION indoor at the wall base through metallic bracket floor anchored |
|
|
CHASSIS aluminum |
|
|
DISPLAY color touch screen 4,3 “ wall mounted |
|
|
CLIMBING TYPES lead and top rope |
|
|
CLIMBING WALLS vertical and overhanging |
|
|
ROPE Dynamic climbing rope diameter 10 mm |
|
|
ROPE LENGHT 35 m |
|
|
ROUTE LENGHT max 17 m on vertical wall |
|
|
CLIMBER WEIGHT min 20 kg max 120 kg |
|
|
ROPE DRIVE electrical motors |
|
|
BRAKE SYSTEM mechanical rope friction system with electromechanical redundancy |
|
|
ACTIVATION with or without RFID card |
|
|
CARD READER at the bottom of the display Rfeed 125 Khz |
|
|
APP Prograde APP for gym and climbers |
|
|
CONSUMPTION 200 Watt/h |
PEAK CONSUMPTION
750 Watt/h
POWER SUPPLY UNIT
DC 24V 750W 30°
POWER SUPPLY
220 VAC 50 Hz
PRODUCT DIMENSION
595 x 250 x 725 mm
PACKAGE DIMENSION
600 x 350 x 800 mm
PACKAGE WEIGHT
MANDATORY
35 kg
WI-FI connection mandatory
Installation on a maximum 30° at wall base
Up to two climbing routes
UIAA
REFERENCE REGULATIONS EU norms certification:
– EN 341:2011 – Dispositivi di discesa per
– salvataggio
– EN 15151-1:2012 – Dispositivi di frenatura;
– UIAA 129_V9 – Braking devices
CERTIFICATION Certification in accordance with standards:
– Direttiva macchine 2006/42/CE
– Direttiva bassa tensione 2014/35/UE
CERTIFICATION BODY DOLOMITICERT
Z.I. Villanova, 7/A – 32013 Longarone (BL) – ITAL
